My FLow Coin 3000

Display Size

5.5" / 14.0 cm

Native Resolution

1920 x 1080

Touchscreen

No

HDR Support

Yes: HDR10/Hybrid Log Gamma

Video I/O

1x HDMI 1.4 Input

Media/Memory Card Slot

Single Slot: SD/SDHC [16 GB Maximum / LUT/Firmware Update Only]

Video Format

HDMI UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p 576i 480p 480i

Battery

1x L-Series/LP-E6 Combination Mount on Fixed Plate

Power Consumption

5.5 W

Display

Panel Type LCD Display Size 5.5" / 14.0 cm Native Resolution 1920 x 1080 Aspect Ratio 16:9 Viewing Angle Horizontal: 160° Vertical: 160° Touchscreen No Maximum Brightness 1000 nits / cd/m2 Contrast Ratio 1000:1 Color Support 1.07 Billion Colors (8-Bit+FRC) HDR Support Yes: HDR10/Hybrid Log Gamma Color Gamut 100% Rec. 709 100% DCI-P3 LUT Support Yes Image Controls Anamorphic De-Squeeze, False Color, Focus Assist, Focus Peaking, Histogram, Image Rotate, Pixel Zoom, RGB Parade, Scaling, Screen Markers, Vectorscope, Waveform, Zebra

Inputs/Outputs

Video I/O 1x HDMI 1.4 Input Embedded Audio HDMI Audio I/O 1x 1/8" / 3.5 mm Headphone Output Power I/O 1x USB-C (17 VDC) Input 1x Barrel (8.4 VDC) Output Other I/O 1x 2.5 mm (Camera Control) Media/Memory Card Slot Single Slot: SD/SDHC [16 GB Maximum / LUT/Firmware Update Only]

Wireless

Wi-Fi No Bluetooth No Mobile App Compatible No

Format Support

Video Format HDMI UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p 576i 480p 480i

Power

Input Power 5 to 17 VDC Battery 1x L-Series/LP-E6 Combination Mount on Fixed Plate Power Consumption 5.5 W

Mounting

Tripod/Accessory Mounting Bottom/Right 1x ARRI Anti-Twist 1/4"-20

General

Environmental Resistance No Operating Conditions 32 to 104°F / 0 to 40°C Material of Construction Aluminum, Polycarbonate Dimensions 6.2 x 3.1 x 0.8" / 157.5 x 79 x 20 mm Weight 6.17 oz / 175.00 g

Package Weight

0.99 lb

Box Dimensions (LxWxH)

7.5 x 6.7 x 2.2"
